Specifications of mesh antenna c band :
1.Customized design welcome
2.OEM accept.
3.100% qualified mesh aluminium.
4.Polyester Power Polishing
5.waterproof cap
Product features:
The SMC reflector of FRP antenna is molded, with high accuracy, good consistency and no deformation;
Low density, high specific gravity, strong as steel, light as aluminum, pressure resistance is 12 times that of aluminum;
Reflection surface of multiple pieces of combination, good interchangeability;
Corrosion resistance, aging resistance, life span up to 15-20 years;
The specially designed feed and the reflection surface perfectly match, so that the sending and receiving reaches the highest efficiency;
Electric polar coordinate tracking structure, can meet the full orbit satellite coverage; installation and adjustment is simple and easy.
Reflective surface orange peel surface is designed to prevent rain and decay and reduce damage to high frequency head.
Technical parameters: 3.0m
electrical character
Operating frequency: C-Band:3.7-4.2GHZ
Ku-Band:10.75-12.95GHZ
Center frequency gain: C-Band: 39.7 dB
Ku-Band:48.8 dB
3dB wavelength: C-Band: 1.7°
Ku-Band:0.6°
First lateral flap: -20dB
Polarization isolation:> 30dB
Voltage-standing wave ratio: <1.3:1
Noise temperature (at 30 elevation): C-Band: 30 K
Ku-Band:26 ºK
Feeder interface: C-Band: CPR229
Ku-Band:WR75
mechanical properties
Reflector material: 8 glass fiber reinforced unsaturated polyester sheet molded plastic (SMC)
Antenna form: central feed
Feeder installation form: single-arm support / three-rod support
Angine adjustment range: 0-90 sustainable fine adjustment
Azimuth adjustment range: 0-360 continuously adjustable
Transportation specification: 220kg
environmental suitability
Wind load: normal operation: 22mps
Preservation: 45mps
Adapt temperature: normal operation: -40ºC ~ 60ºC
Preservation: -45ºC ~ 70ºC
Atmospheric conditions: suitable for humid, large salinity, polluted climate environment
| Item No | 180CM | |
| Panel | 4 | |
| Aperture Diameter | 180CM | |
| C-Band Gain@ 4GHz | 35dB | |
| F/D Ratio | 0.35 | |
| Focus Length | 65CM | |
| Material | Aluminium mesh | |
| Finish | Polyester Powder Coating | |
| Mounting Type | fix mount | |
| Elevation Alignment | 0~60°/0~90° | |
| Azimuth Alignment | /0~360° | |
| Operational Winds | Able to receive | 25m/sec |
| Able to re-set | 40m/sec | |
| Not broken & fly away | 60m/sec | |
| Ambient Temperature | -40°C~+60°C | |
| Relative Humidity | 0~100% | |
C band mesh antenna 2.1M specification:
| Item No | 210CM | |
| Panel | 4 | |
| Aperture Diameter | 210CM | |
| C-Band Gain@ 4GHz | 36.8dB | |
| F/D Ratio | 0.385 | |
| Focus Length | 80.8CM | |
| Material | Aluminium mesh | |
| Finish | Polyester Powder Coating | |
| Mounting Type | fix mount | |
| Elevation Alignment | 0~60°/0~90° | |
| Azimuth Alignment | /0~360° | |
| Operational Winds | Able to receive | 25m/sec |
| Able to re-set | 40m/sec | |
| Not broken & fly away | 60m/sec | |
| Ambient Temperature | -40°C~+60°C | |
| Relative Humidity | 0~100% | |
C band mesh antenna 2.4M specification:
| Item No | 240CM | |
| Panel(Sector Divided) | 4 | |
| Aperture Diameter | 240CM | |
| C-Band Gain@ 4GHz | 38.39dB | |
| Ku-Band Gain@ 12.5GHz | ||
| F/D Ratio | 0.385 | |
| Focus Length | 92.4CM | |
| Material | Aluminium Mesh | |
| Finish | Polyester Powder Coating | |
| Mounting Type | Pole/Polar Mount | |
| Elevation Alignment | 0-90 | |
| Azimuth Alignment | 0-360 | |
| Operational Winds | Able to receive | 25m/sec |
| Able to re-set | 40m/sec | |
| Not broken & fly away | 60m/sec | |
| Ambient Temperature | -40-+60 | |
| Relative Humidity | 0-100% | |
We can supply two type of the mesh antenna:
1.Pole mount:used for satellite signal receiving.
2.Polar mount: used with motor Automatic find the satellite signal.
