Basic Info.
Model NO.
GL433V3
Base Antenna
Omnidirectional Antenna
Nature of Operation
Omnidirectional Antenna
Sturcture Form
Surface Antenna
Dimensionality
One-Dimensional Antenna
Qty/CTN
20PCS
Fob Port
Guangzhou
MOQ
100
Payment
Tt,Paypal
Transport Package
20PCS/CTN CTN Size: 97*20*39.5cm
Specification
20*430mm
Trademark
LEHENG
Origin
China
HS Code
8529109090
Production Capacity
1000PCS/Day
Product Description
| Technical Data | |
| Frequency | 428-438MHz |
| V.S.W.R | ≤1.5 |
| Gain | 3dBi |
| Horizontal Beam Width | 360° |
| Vertical Beam Width | 35° |
| Polarization | Vertical |
| Input Impedance | 50Ω |
| Max Power | 50W |
| Lighting Protection | DC Ground |
| Mechanical Data | |
| Connector type | TNC female |
| Connector position | Bottom |
| Antenna dimension | Ф19×565mm |
| Antenna Weight | 1.5kg |
| Antenna radome material | Fiberglass |
| Antenna radome color | gray |
| Working temperature | -40°c~60°c |
| Rated wind velocity | 60 m/s |
| Pole Diameter | ¢35~¢60 |
Q: Can I get one sample?
A: Yes, sample is available.
Q: Have GNSS Antenna 100% assembles well in stock?
A: No, all GNSS antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 3-5 working days for the sample, 10-15 working days for quantity below 5K,.
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A:T/T, Paypal, Western Union etc.
Q:May I visit your company?
A: Sure, welcome any time.
Q: How long of the warranty?
A: one year for antennas and half a year for assembly cables and connectors
