Basic Info.
Model NO.
GKZS-GPS&GSMY-SMAJZG3-T
Nature of Operation
Receiving Antenna
Sturcture Form
Surface Antenna
Connector
SMA Male
Cable
Rg174 3meter
Transport Package
Plastic Bags in Carton
Specification
46x16mm
Trademark
Gkant
Origin
China
HS Code
8529101000
Production Capacity
50000000PCS/Month
Product Description
Antenna indicator:
| Design Specifications | Typical | Units | |
| Antenna form | External Antenna | ||
| working Frequency | 1575.42±5MHz | 824-960MHz 1710-1990MHz | MHz |
| Gain | ≤2.5dBi | ≤2.0dBi | dBi |
| Antenna efficiency | 50% | 30% | |
| VSWR | ≤2.0 | ≤2.0 | |
| Ploriaztion | RC Pol | L Pol | |
| Axial Ratio | ≤3.0 | / | |
| Radiation pattern | Omni | Omni | |
| impedance | 50Ω | 50Ω | Ω |
| Power handling | 33dbm | 33dbm | dbm |
| Interface | SMA Male/RG174 Cable 3M | SMA Male/RG174 Cable 3M | |
| Overal dimensions | Ø46x16mm | mm | |
| Weight | 98.4g | g | |
| Operatin Temp | -40ºC~85ºC | ºC | |
| Storing Temp | 15ºC~30ºC | ºC | |
Amplifier characteristics
| NO | Item | Specifications |
| 1 | Frequency Range | 1575.42MHz |
| 2 | Amplifier gain | 28dBi±3 |
| 3 | V.S.W.R | ≤2.0 |
| 4 | Noise Figure | <2.0 |
| 5 | DC Voltage | 3~5V |
| 6 | DC Current | ≤20mA |
Q: What type of antenna your factory have ?
A:We have shark fin antenna, GPS & Beidou & GLONASS, 2.4G, GSM, 3G, 4G, DVB-T, 433MHz, RFID, flat panel, Yagi, array, FRP andother antennas, various wire harnesses and connecting wires.
Q: Can your factory accept customize?
A: Of course. Personalized designs of the products according to customer's requirements are welcomed.For example, we can customize cable length(1M, 2M,3M...)and connectors(SMA serial ,MCX, Fakra, TS9, CRC9...) for you.
Q:Why should we choose our company as business partner?
A:We have more than 20 years of experience in product development and application analysis, because we have fast product development and application services. Large investment in R & D equipment.
