Basic Info.
Product Description
R330 Selling Points:
2.5.0 inch HD display, 1280*720 IPS, mobile cashier, smarter and more secure
3. Built-in 75mm/s high speed 58mm thermal printer , with over 50Km print life
4.Full bands for global coverage: 4G/3G/2G,WLAN, BT, GPS
5. Rear Camera: 5M, AF(Auto Focus), LED Fake fIash
The price on the product detail page is the standard configuration price;
General
The R330 is the secure electronic payment terminal powered by safe-Android 7.1 operation system. It comes with a 5.0 inch high definition colorful display, industrial level thermal printer and flexible configuration for various barcode scanner scenarios. A wide range of advanced connectivity options are supported for global 2G/3G/4G network, as well as inbuilt NFC,CCD(Optional) contactless, BT3.0/4.2 and WIFI.Features
- Senraise OS, Based on Android 7.1 OS;
- 5.0 inch HD display, 1280*720 IPS, mobile cashier, smarter and more secure;
- Built-in 75mm/s high speed 58mm thermal printer , with over 50Km print life;
- Full bands for global coverage: 4G/3G/2G,WLAN, Bluetooth, GPS;
- Rear Camera: 5M, AF(Auto Focus), LED Fake fIash;
| Introduction | R330 Smart Handheld POS Terminal |
| Processor | Snapdragon 425, 1.4GHz, Quad-core, Cortex-A53 |
| Memory | 2GB RAM, 16GB Flash |
| OS | Android 7.1 |
| Display | 5.0'' HD, 1280*720 IPS; G+FF multi-capacitive touch |
| Key PAD | Power on / off, Volume up / Scanner |
| Card Slot Support | SIM: 1*SIM Card ( 1.8v / 3.0 v ) |
| Fiscal Module | Support 12C or UART interface 30.0±0.2*30.0±0.2*9.2±0.2 mm |
| Data Connect | Communication: 4G(Full band)/3G/2G |
| WIFI: 2.4G/5GHz,Support IEEE802.11a/b/g/n | |
| Bluetooth: Support 3.0/4.0, BLE, ibeacon | |
| GPS | Built-in GPS, support A-GPS |
| Thermal Printer | High-speed 58mm line, 40 mm Roll, low noise, power saving |
| Camera | Rear Camera: 5.0 M, AF (automatic focus) |
| Front Camera(Optional): 0.3 M 3P, FF (Fixed-focus) | |
| Battery | Two 18650 cell from samsung ( ICR 18650-26J ) 7.4v / 2600 mAh |
| Speaker | 0.8 W / 85 dB |
| Earphone-jack | 3.5mm standard, support external RFID reader via this connector |
| Interface | 1*Micro USB connector, support OTG USB to RJ45 network |
| Adaptor | Input: AC 100~240v, 0.5 A, output: 5v / 2 A |
| Dimensions | 198*79*48 (L*W*H) mm |
| Anti-Drop | 1.2 meter |
| Certification | CE, ROHS |
| Optional | NFC: ISO/ICE14443, Type A/B, Mifare Card |
| Support 1D CCD barcode scanning and reading |
1.What is your business scope?
We have been in PC/POS/Mobile Payment product & Solution for 10 years. We can provide OEM / ODM customized service
according to our customers' various application and demands.
2.What is your mode of payment?
T/T, PAYPAL, Western Union, L/C, Trade Assurance, Credit Card, Cash, MoneyGram, D/P, D/A etc.
3.When will you delivery the goods?
Sample: 2-7 days;
Quantity order: 7-30 days upon deposit received;
Customized Product: according to the contract delivery time.
4.Would you provide SDK for me?
Yes, We offer free SDK if you order sample. All the contents in a CD ROM with sample together.
5.What is the FOB price and CIF price
In general, our prices are given on a FOB basis. For CIF price, I will check the cost from our shipping agent and recommend to you.
6.How can you guarantee the quality?
We have well-trained and professional workers and strict QC system in each production link. And each product has to be 100% inspected before shipment.
7.How can you guarantee the exclusive sale for OEM & ODM service?
Product mould contract, non-disclosure agreement, exclusive sale agreement will be signed before starting the OEM & ODM project.
8.What the after sale service?
a. Our all products will provide 12 months warranty;
b. Enough stock spare parts for guarantee;
c. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
d. As for the returned failure products, we will fix it and return to the customers in one week after we received it.
