Basic Info.
Model NO.
EW1612-GI
Specification
Module Size 16X12X2.6 mm
Trademark
Delincomm
Origin
China
Production Capacity
100000PCS/Month
Product Description
Delin comm EW1612-GI is a satellite navigation receiver capable of using L5 NavIC, L1 GAGAN/GPS/GLONASS signal to provide 3D navigation in a single compact SMD
The Delin comm EW1612-GI is a satellite navigation receiver capable of using L5 NavIC, L1 GAGAN/GPS/GLONASS signal to provide 3D navigation in a single compact SMD module. The EW1612-GI has 56 tracking channels and could track all in‐view satellites. It is fully autonomous such that once power is applied, the receiver automatically searches, acquires and tracks satellite signals. When a sufficient number of satellites are tracked with valid measurements, the receiver produces 3D position and velocity outputs.
NavIC + GPS/GLONASS triple‐satellite capability enables using greater number of satellite signal than GPS‐only receivers. The increased satellite number offers superior performance in challenging urban can yon and multipath environments.
The Delin comm EW1612-GI module contains Delin comm Venus 8 positioning engine inside, featuring high sensitivity, low power consumption, and fast TTFF. The superior cold start sensitivity allows it to acquire, track, and get position fix autonomously in difficult weak signal environment. The receiver's superior tracking sensitivity allows continuous position coverage in nearly all outdoor application environments. The high performance signal parameter search engine is capable of testing 16 million time‐frequency hypotheses per second, offering superior signal acquisition and TTFF speed.
Applications
The Delin comm EW1612-GI is a satellite navigation receiver capable of using L5 NavIC, L1 GAGAN/GPS/GLONASS signal to provide 3D navigation in a single compact SMD module. The EW1612-GI has 56 tracking channels and could track all in‐view satellites. It is fully autonomous such that once power is applied, the receiver automatically searches, acquires and tracks satellite signals. When a sufficient number of satellites are tracked with valid measurements, the receiver produces 3D position and velocity outputs.
NavIC + GPS/GLONASS triple‐satellite capability enables using greater number of satellite signal than GPS‐only receivers. The increased satellite number offers superior performance in challenging urban can yon and multipath environments.
The Delin comm EW1612-GI module contains Delin comm Venus 8 positioning engine inside, featuring high sensitivity, low power consumption, and fast TTFF. The superior cold start sensitivity allows it to acquire, track, and get position fix autonomously in difficult weak signal environment. The receiver's superior tracking sensitivity allows continuous position coverage in nearly all outdoor application environments. The high performance signal parameter search engine is capable of testing 16 million time‐frequency hypotheses per second, offering superior signal acquisition and TTFF speed.
Applications
- Navigation and asset tracking
- Timing reference
1,L1 / L5 signal reception
2,Works with NavIC, GAGAN, GPS, GLONASS
3,Less than 30 second cold start TTFF
~ 1 second hot start
~2.5m CEP accuracy
4,Multipath detection and suppression
5,Works with passive and active antenna
6,Complete receiver in 12mm x 16mm size
7,Operating temperature ‐40 ~ +85ºC
8,Pb‐free RoHS compliant
2,Works with NavIC, GAGAN, GPS, GLONASS
3,Less than 30 second cold start TTFF
~ 1 second hot start
~2.5m CEP accuracy
4,Multipath detection and suppression
5,Works with passive and active antenna
6,Complete receiver in 12mm x 16mm size
7,Operating temperature ‐40 ~ +85ºC
8,Pb‐free RoHS compliant
