Basic Info.
Model NO.
SWT-JRT-BGL25
Weight
≤1.2kg
Size
≤175mm*150mm*25mm
Power Supply
DC6V~DC36V
Power Consumption
10W(28V/0.36A)
Channel Isolation (dB)
≥60dB
Connectors
TNC
Phase Consistency
≤5
Transport Package
Carton
Specification
175mm*150mm*25mm
Trademark
SWT
Origin
China
Production Capacity
1000 / 3 Months
Product Description
- Function
- Receive the Receive RF signal of GPS L1 and BD2-B1, and realize the anti-jamming function;
- Receive and amplify GLONASS signal with low noise, and output the signal with B1 RF signal(anti-jamming).
| 4 L1/B1 Elements,1 Element GLONASS |
| ≤1.2kg |
| -65dBm±5dBm |
| ≤175mm*150mm*25mm (Height does not include connectors); mounting hole:155mm x 75mm |
| Anti - three - wideband jammings (4MHz): 75dB~80dB; Anti - wideband jamming: 80dB~85dB; Anti one CW Jamming: 85dB~90dB |
| DC 6V~DC 36V |
| 40dB±1dB |
| 10W(28V/0.36A) |
| ≥60dB |
| RF connector:TNC type High frequency electrical outlet& Power supply:J30J-9ZKP |
| ≤5o |
| / |
| ≤1dB |
| -40ºC~85ºC |
| Comply with GJB requirements |
| -55ºC~85ºC |
- Applications
- Combat vehicles, aircraft, unmanned aerial vehicles, missiles, ships and other equipment.
