Basic Info.
Product Description
High gain, stable signal, wide coverage
Factory direct sales, fast delivery and affordable price
Support customization: frequency band customization: 433/470/2.4G/5G/5.8G/2G/3G/4G/GSM/GPRS and other frequency band customization
Interface customization: support line length/interface/line diameter/antenna size customization
| Design Specifications | Typical | ||
| Antenna form | External Antenna (Combination) | ||
| Working Frequency | 699-960MHz,1710-2690MHz,3300-4200MHz,4400-5000MHz(5G*4) | 5905-5925MHz(V2X*2) | 1575MHz±20MHz,1176MHz±20MHz(GPS L1 & GPS L5*1) |
| Gain | -2.56dBi(average)@699-960MHz,1710-2690MHz -3.37dBi(average)@3300-4200MHz,4400-5000MHz | -4.01dBi(average) | 3.0dBi |
| Antenna efficiency | 21.51%(average)@699-960MHz,1710-2690MHz 12.98%(average)@3300-4200MHz,4400-5000MHz | 10.35%(average) | 45% |
| VSWR | ≤2.5@1710-2690MHz | ≤3.0 | ≤2.0 |
| Ploriaztion | linear | linear | R |
| Impedance | 50Ω | 50Ω | 50Ω |
| Overal dimensions | 155x75x28mm | 155x75x28mm | 48x48x19.5mm |
| Interface | Mini-FAKRA4pin/ RG174()3m | ||
| Weight | 460g | ||
| Operatin Temp | -40ºC~80ºC | ||
| Storing Temp | -40ºC~80ºC | ||
Antenna technical parameters: Amplifier characteristic
| LNAGain(dB) | 26±3 | |
| Output VSWR | <2.0 | |
| Output impedence(ohm) | 50 | |
| (1575.42±3MHz&1176±3MHz)Passband Ripple(dB) | ±3 | |
| Out of band rejection | 1575MHz±25MHz | 30dBc min |
| 1176MHz±20 MHz | 30dBc min | |
| Prime power(V) | 3.3~5 | |
| Operating current(mA) | <20 | |
GaoKe Ant Co.,Ltd is Antenna and RF Co-axial Cable assembly manufacturer nearly 30 years from Guangzhou,China. We deal in all types of antenna, antenna cables,rf connector, rf Co-axial Cable, jumper cables, pls confirm if any enquiry across..Our R&D team will provide you with technical support and antenna solution design.
1.Q: Are you a manufacturer?
A: Yes, our company has nearly 30 years of professional experience dealing with wireless communication and develop ,produce and sale satellite communication products professionally
2.Q: How do I get samples?
A: Please send us the item link you need and your shipping address,we will check the shipping fee and confirm with you.After we receive the fee,we will send in 3-5 days by express.Some samples will charge sample fee, please confirm with us at first.
3.Q: How to make an OEM order?
A: 1. After communication, the buyer and the seller reach an agreement on product details, packaging, purchase quantity, unit price, delivery terms and payment terms.
2. The buyer sends a formal PO (purchase order) or the seller sends a formal PI (performance invoice) with detailed terms and conditions.
4.Q: What are your payment terms?
A: For samples: small batch orders or urgent orders, you can choose PayPal, Western Union, MoneyGam, Escrow to facilitate buyers, 100% payment before shipment; for large orders: 30%/50% of T/T as deposit, The balance before shipment.
5.Q: How long is your delivery time?
A: For example: usually 7-15 working days after receiving your 100% payment.
For bulk orders: 15-35 working days after receiving the deposit.
6.Q: How about the warranty?
A: We can provide 1 year warranty.
7.Q: How do you solve after-sales service problems?
A: After receiving the goods, if you have any dissatisfaction or other problems, please contact us as soon as possible, we will give you a quick and reasonable solution, thank you very much!
8.Q: If we want a special appearance and function increase, can we get support?
A: No problem! Our R&D team will support you to develop a new and best product for you!
