Basic Info.
Model NO.
2G-3G
Base Antenna
N/a
Nature of Operation
Recieve and Transimit
Sturcture Form
Wire Antenna
Dimensionality
Rhcp
Automotive
Yes
NF
<2.0dB
Application
Car
Size
49.2X39.2X15mm
Big or Small
Small
Transport Package
Box
Specification
OEM
Trademark
CTW
Origin
Changzhou
Product Description
Product Specification
Features and Benefits
Applications
| Item | Specification | |||
| GPS Antenna | Ceramic microstrip antenna | CF | 1575.42MHz | |
| BW | CF±5MHz | |||
| Polarization | RHCP | |||
| Gain | 2.5dBic(Zenith) | |||
| VSWR | <=1.5 | |||
| Axial Ratio | 3dB(max) | |||
| Impedance | 50Ω | |||
| LNA | Gain | 28±2dB | ||
| NF | <=1.5 | |||
| VSWR | <=2.0 | |||
| With table attenuation | 30dB@CF+50MHz/20dB@CF+50MHZ | |||
| Supply voltage | 3.0V-5.0V | |||
| Current consumption | <=25mA | |||
| Mobile communication main antenna | Frequency range | 824-960MHz/1710-2690MHz | ||
| VSWR | <=2.5 | |||
| Polarization | Linear polarization | |||
| Gain(Typical value) | >=1.0dBi | |||
| Impedance | 50Ω | |||
| Mobile communication sub antenna | Frequency range | 1710-2690MHz | ||
| VSWR | <=2.5 | |||
| Polarization | Linear polarization | |||
| Gain(Typical value) | >=1.5dBi | |||
| Impedance | 50Ω | |||
| Structure | Coaxial line | RG174/Length 2m | ||
| Connector | FAKRA/TNC | |||
| Installation method | Tape paste | |||
| Radome material | PC/ABS | |||
Features and Benefits
- Strong R&D team which is dedicated to research,design,analyze and test innovative antenna systems
- Professional and efficient mechanical and RF simulation toolis to make sure the perfect antenna performances
- One stop solution to design and manufacture all kinds of antennas for industrial and automotive applications
- Provided quad band,muti-function module,AM/FM short whip,embedded BT antenna,stealth GSM and GPS antenna,and the TPM antenna,RFID antenna
- Customeized and standard antennas design and manufacture
- Strict quality control and end to end process
Applications
- Industrial RFID antenna
- Asset tracking external /internal antenna
- Automotive muti-function antenna
- Wireless alam,security and monitoring systems
- Vehicle tracking systems
FAQ
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q:May I visit your factory?
A: Sure, welcome any time.
Q: What's your company MOQ?
A: our company don't have MOQ. We also accept small quantity.
Q: Can your company accept customize?
A: Welcome OEM & ODM.
Q: What's your delivery time?
A:If our company have stock ,will send to you within one day once receive your deposit.
If use customer brands, we will take some days to prepare materials and mass production.
Q: How do you solve after sale service?
A: This please ask us for technical support if you have workers know how to repair.
If do not have engineers, please send back the items, we can repair the items for you or we will re-produce for you.
Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can be sent out once you ask for it, if the samples cost is very higher , we will ask a sample fee.At the same time. the Sample fee will return back in future order. If the
samples cost is lower, we can send it to you free, but shipping cost will be took .
