Basic Info.
Model NO.
DL-GPS&GLONASS-TC3540-J
Base Antenna
Directional Antenna
Nature of Operation
Receiving Antenna
Sturcture Form
Surface Antenna
Dimensionality
Two-Dimensional Antenna
Antenna Size
35X35X4mm
Package
Plastic Tray , Paper Cartoon
Connector
SMA Head
Impedance
50 Ω
Transport Package
Plastic Tray, Paper Cartoon
Specification
Antenna Size: 35X35X4mm
Origin
China
Production Capacity
100000PCS/Day
Product Description
GPS&Glonass Built-in Receiving Antenna with Size 35X35X4mm
1. SCOPE
This Delin Comm specification shall cover the characteristics of the dielectric antenna element with the type DL-GPS&GLONASS-TC3540-J. 1. SCOPE
2. Performance Characteristics
* Center frequency :-10dB bandwidth center frequency. depend on the ground plane of customers.
| Items | Specification |
| Range of Receiving Frequency | 1575~1608MHz (GPS : 1575, GLONASS : 1592~1608) |
| Center frequency | 1602±3.0 MHz |
| -10dB Bandwidth MHz min | 35 |
| VSWR at CF max | 1.5 |
| Polarization Model | RHCP |
| Impedance | 50 Ω |
| Frequency Temperature Coefficient | 20ppm/deg.ºC max |
