Basic Info.
Model NO.
GL-DY005
Material
ABS
Directionality
Directional Antenna
VSWR
<1.5
Base Antenna
High Gain Antenna
Nature of Operation
Receiving Antenna
Sturcture Form
Surface Antenna
Dimensionality
Two-Dimensional Antenna
Connector
TNC Female
Transport Package
53*23*29cm, 100PCS/CTN
Specification
65*56*18mm
Trademark
LEHENG
Origin
China
HS Code
8517707090
Production Capacity
3000PCS/Day
Packaging & Delivery
Package Size
60.00cm * 45.00cm * 48.00cm
Package Gross Weight
30.000kg
Product Description
GPS navigation antenna,
Waterproof,
Anti-corrosion,
Lightning protection devices.
The built-in amplifier, can resistance to
electromagnetic Interference and to receive
satellite signals to the low angle.
FEATURES
FAQ
Q: Can I get one sample?
A: Yes, sample is available.
Q: Have GNSS Antenna 100% assembles well in stock?
A: No, all GNSS antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 3-5 working days for the sample, 10-15 working days for quantity below 5K,.
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A:T/T, Paypal, western union etc.
Q:May I visit your company?
A: Sure, welcome any time.
Q: How long of the warranty?
A: one year for antennas and half a year for assembly cables and connectors
Zhengzhou LEHENG Electronic Technology Co.,Limited is located in Zhengzhou,Henan,was founded in the year 2016,Which is the central plains,it is the largest logistics transportation and transit center in Asia.Its Hong Kong Company GLOBAL EAST ASIA TECHNOLOGY CO.,LTD,was built up in the year 2014.
Our main products: GPSGLONASS Antennas,GPS Receiver Modules,5G Antennas,Combo Antenna,GSM/3G Antennas,4G/LTE Antennas,433MHz and 868MHz Antennas,TV Antennas, MIMO Antennas,WIFI Antennas,WLAN and WIMAX Antennas,Various connectors and cables assembly.
Our principle of service: Service-first,Integrity-based,quality-oriented. With the operation principle of innovation,pragmatic,efficient and win-win business philosophy,Zhengzhou LEHENG Electronic Technology Co.,Limited has made remarkable achievements through the extension of the corporate culture and continue to expend new markets by our all staff's tireless efforts. We have partners all over the world,even has become the sole agent of many European and American traders in China, and enjoy a good reputation in the industry over the years.
To create value for customers,creating opportunities for staffs and for social responsibility is our working goals.
We firmly believe that: Stable operation and continued to enhance corporate value, abide by its commitment,to provide customers with first-rate service and high quality products is the code of conduct which we have to adhered.
Waterproof,
Anti-corrosion,
Lightning protection devices.
The built-in amplifier, can resistance to
electromagnetic Interference and to receive
satellite signals to the low angle.
FEATURES
- Miniature size (96mm 96mm 127mm)
- Worries about where to install are eliminated, wiring is simplified.
- Customized connector and cable are available.
- Various optional extras (mounting fixtures, spongers, and clips, etc.) are available to satisfy your needs.
- Connector types: SMA, MCX, MMCX, SMB, TNC, BNC…
| Antenna | Item | Specifications |
| Reception frequency | 1575.42MHz | |
| bandwidth | ±10MHz | |
| Reception polarization | RHCP | |
| Antenna gain | 3dBic | |
| Output impedance | 50Ω | |
| LNA | Reception frequency | 1575±10MHz |
| Noise factor | <1.0 | |
| Gain | 42±2dB typ. | |
| VSWR | <1.5 | |
| DC current | <7mA | |
| Overall | Max Power | 50mW |
| Cable | SYV50-3/5/7 | |
| Antenna weight | 0.15kg | |
| Power supply voltage | 2.7V to 5.0V | |
| Shell color | white | |
| Waterproof | 100% | |
| Working temp | -30ºC~85ºC |
