Product Description
Lora rubber 433mhz uhf antenna
| Item | Specifications | |||
| Antenna | Center Frequency | 433MHz | ||
| Band Width | CF±5MHz | |||
| Polarization | Linear | |||
| Gain | 2dBi(Zenith) | |||
| V.S.W.R(min) | <2.0 | |||
| Impendance | 50Ω | |||
| Mechanical | Cable | RG178 | ||
| Connector | IPEX or others | |||
| Mounting Method | Screw | |||
| Environmental | Operating Temperature | -40ºC~+85ºC | ||
| Relative Humidity | Up to 95% | |||
| Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |||
| Environmentally Friendly | ROHS Compliant | |||
Q: Are you a manufacturer or a trading company?
A: We have been professional antenna manufacturer for 20+ years.
Q: Can I get one sample?
A: Yes, sample is for free.
Q: Have gps gsm combo antenna 100% assembles well in stock?
A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 1-5days for the sample, 5-10 days for quantity below 5K, 10-30 days for the quantity below 20K.
Q: Could I use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A: T/T, Paypal, western union etc.
Q: Where is your factory located? Can I visit your factory?
A: Factory address: #398 Zhenye Road, Jiaxing Economic Development Zone, Nanhu District, China. Just call us, we will pick you up with no delay.
Q: How long of the warraty?
A: One year and can repair for the whole life.
