Basic Info.
Model NO.
GKZS-S4G&GPS&BD-FAKRAZM3-ASWG
Base Antenna
Directional Antenna
Nature of Operation
Receiving Antenna
Sturcture Form
Wire Antenna
Dimensionality
One-Dimensional Antenna
Frequency Range(MHz)
1575.42±5/1561.09±5MHz
Amplifier Gain(dBi)
26±3dBi
Transport Package
Plastic Bags in Carton
Specification
83x16x6.5mm
Trademark
Gkant
Origin
Guangzhou China
Production Capacity
50000PCS/Month
Product Description
Antenna technical parameters
Amplifier characteristics
V.S.W.R
Return Loss
GPS/BD antenna receiving chart
1.Q: Are you a manufacturer?
A: Yes, our company has 30 years of professional experience dealing with wireless communication and develop ,produce and sale satellite communication products professionally
2.Q: How do I get samples?
A: Please send us the item link you need and your shipping address,we will check the shipping fee and confirm with you.After we receive the fee,we will send in 3-5 days by express.Some samples will charge sample fee, please confirm with us at first.
3.Q: How to make an OEM order?
A: 1. After communication, the buyer and the seller reach an agreement on product details, packaging, purchase quantity, unit price, delivery terms and payment terms.
2. The buyer sends a formal PO (purchase order) or the seller sends a formal PI (performance invoice) with detailed terms and conditions.
4.Q: What are your payment terms?
A: For samples: small batch orders or urgent orders, you can choose PayPal,or bank account 100% payment before shipment; for large orders: 30%/50% of T/T as deposit, The balance before shipment.
5.Q: How long is your delivery time?
A: For example: usually 7-15 working days after receiving your 100% payment.
For bulk orders: 15-35 working days after receiving the deposit.
6.Q: How about the warranty?
A: We can provide 1 year warranty.
7.Q: How do you solve after-sales service problems?
A: After receiving the goods, if you have any dissatisfaction or other problems, please contact us as soon as possible, we will give you a quick and reasonable solution, thank you very much!
8.Q: If we want a special appearance and function increase, can we get support?
A: No problem! Our R&D team will support you to develop a new and best product for you!
| Design Specifications | Typical | ||
| Working Frequency | 824-960MHz 1710-2170MHz 2300-2690MHz | 1710-2170MHz 2300-2690MHz | 1575.42±5/1561.09±5MHz |
| Gain | ≤2.5dBi | ≤2.0dBi | 3.0dBi |
| Antenna efficiency | 45% | 40% | 50% |
| VSWR | ≤2.5 | ≤2.5 | ≤2.0 |
| Ploriaztion | L Pol | L Pol | RC POL |
| Axial Ratio | / | / | ≤3.0 |
| Radiation pattern | Omni | Omni | Omni |
| Impedance | 50Ω | 50Ω | 50Ω |
| Power handling | dBm | dBm | 33dBm |
| Interface | FAKRA-D/RG174-3M | FAKRA-E/RG174-3M | FAKRA-C/RG174-3M |
| Overal dimensions | 83x16x6.5mm | 83x16x6.5mm | 48.5x37x19mm |
| Weight | 179.4g | ||
| Operatin Temp | -40ºC~85ºC | ||
| Storing Temp | -45ºC~85ºC | ||
| NO | Item | Specifications) |
| 1 | Frequency Range(MHz) | 1575.42±5/1561.09±5MHz |
| 2 | Amplifier gain(dBi) | 26±3dBi |
| 3 | V.S.W.R | ≤2.0 |
| 4 | Noise Figure | ≤2.0 |
| 5 | DC Voltage(V) | 3~5V |
| 6 | DC Current(mA) | ≤20mA |
