Basic Info.
Model NO.
GPS+GSM
Base Antenna
Automotive Antenna
Nature of Operation
Recieve and Transimit
Sturcture Form
PCBA with Cable
Dimensionality
Linear
Impedance
575Ω
Gain
28dB±2dB
Size
59.2mm X 52.5mm X 15mm
Coaxial Cable
Rg174 / Length 3meters
Connector
Fakra
Installation Method
Tape and Magnet
Shell Material
PC/ABS
Transport Package
Box
Trademark
CTW
Origin
Changzhou
HS Code
8512900000
Product Description
OEM GPS GSM Antenna
Product Specification
CTW is founded in the end of 2013. We a aglobal professional provider for connectors, antennas and wire harness.
We are dedicated to providing innovative solutions & high quality products for industrial, telecommunications & networking, military, medical and automotive markets.
Global professional provider for antennas ,cable assembly, precision parts & assembly, industrial connectors.
Dedicated to provide innovative solutions & high quality products for industrial, telecommunication, military, medical and automotive markets.
Professional & experienced R&D/Engineering team who are dedicated on research and development.
Rigorous and controlled manufacturing process and excellent quality system.
Features and Benefits
1) More than 28 R& D Employees.
2) around have 15 new palents every year .
3) Re-investment in R & D.
4) competitive R&D system.
5) complated laboratory lab
6) high level design capability .
| Item | Specification | |||
| GPS Antenna | Ceramic microstrip antenna | CF | 1575.42MHz | |
| BW | CF±5MHz | |||
| Polarization | RHCP | |||
| Gain | 2.5dBic(Zenith) | |||
| VSWR | <=1.5 | |||
| Axial Ratio | 3dB(max) | |||
| Impedance | 50Ω | |||
| LNA | Gain | 28±2dB | ||
| NF | <=1.5 | |||
| VSWR | <=2.0 | |||
| With table attenuation | 30dB@CF+50MHz/20dB@CF+50MHZ | |||
| Supply voltage | 3.0V-5.0V | |||
| Current consumption | <=25mA | |||
| Mobile communication antenna | Frequency range | 824-960MHz/1710-2690MHz | ||
| VSWR | <=2.5 | |||
| Polarization | Linear polarization | |||
| Max Gain | 2dBi | |||
| Impedance | 50Ω | |||
| Structure | Coaxial line | RG174/Length 1.2m | ||
| Connector | FAKRA | |||
| Installation method | Tape paste | |||
| Radome material | PC/ABS | |||
| Working environment | Operating temperature | -40ºC~+85ºC | ||
| Relative humidity | 95% | |||
| shock | 5Hz-200Hz Per axis 8 hours | |||
| Surroundings | Meet ROHS | |||
CTW is founded in the end of 2013. We a aglobal professional provider for connectors, antennas and wire harness.
We are dedicated to providing innovative solutions & high quality products for industrial, telecommunications & networking, military, medical and automotive markets.
Global professional provider for antennas ,cable assembly, precision parts & assembly, industrial connectors.
Dedicated to provide innovative solutions & high quality products for industrial, telecommunication, military, medical and automotive markets.
Professional & experienced R&D/Engineering team who are dedicated on research and development.
Rigorous and controlled manufacturing process and excellent quality system.
Features and Benefits
- Strong R&D team which is dedicated to research,design,analyze and test innovative antenna systems
- Professional and efficient mechanical and RF simulation toolis to make sure the perfect antenna performances
- One stop solution to design and manufacture all kinds of antennas for industrial and automotive applications
- Provided quad band,muti-function module,AM/FM short whip,embedded BT antenna,stealth GSM and GPS antenna,and the TPM antenna,RFID antenna
- Customeized and standard antennas design and manufacture
- Strict quality control and end to end process
- Industrial RFID antenna
- Asset tracking external /internal antenna
- Automotive muti-function antenna
- Wireless alam,security and monitoring systems
- Vehicle tracking systems
1) More than 28 R& D Employees.
2) around have 15 new palents every year .
3) Re-investment in R & D.
4) competitive R&D system.
5) complated laboratory lab
6) high level design capability .
