Basic Info.
Model NO.
Antenna Cable-32
Base Antenna
High Gain Antenna
Nature of Operation
Receiving Antenna
Sturcture Form
Surface Antenna
Dimensionality
One-Dimensional Antenna
Transport Package
Sea/Air
Trademark
Romtronic
Origin
China
HS Code
8544421100
Production Capacity
20000
Product Description
Outdoor IP67 FRP Antenna Fiber Glass 433 MHz 0.8dB Length 200mm 77-81
Hiwave is a professional antenna manufacturer in R & D, design, manufacture. We have strong R & D strength, flexible and fast design capabilities to meet the needs of our customers.
Electrical Characteristics
Frequency: 433 MHz
Gain: 0.8 dBi
Horizontal Beamwidth: 360 ˚
Vertical Beamwidth: 46 ˚
V.S.W.R: 2.0:1 Max.
Polarization: Linear
Impedance: 50 OHM
Max. Power: 50W
Lightning protection: DC Groud
Material & Mechanical Characteristics
Dimension: Φ16*200mm
Connector: N Connector
Weight: 0.069 Kg
Rated Wind Velocity: 36.9m/s
Hiwave is a professional antenna manufacturer in R & D, design, manufacture. We have strong R & D strength, flexible and fast design capabilities to meet the needs of our customers.
Electrical Characteristics
Frequency: 433 MHz
Gain: 0.8 dBi
Horizontal Beamwidth: 360 ˚
Vertical Beamwidth: 46 ˚
V.S.W.R: 2.0:1 Max.
Polarization: Linear
Impedance: 50 OHM
Max. Power: 50W
Lightning protection: DC Groud
Material & Mechanical Characteristics
Dimension: Φ16*200mm
Connector: N Connector
Weight: 0.069 Kg
Rated Wind Velocity: 36.9m/s
