Basic Info.
Model NO.
ATC-M10
Connector
F Type/SMA/Fakra or Others
Transport Package
Poly Bag/Color Box/Double Blister
Specification
RoHS, ISO/TS16949-2009
Trademark
ATC
Origin
China
HS Code
8529109090
Production Capacity
20, 000PCS/Month
Product Description
company information
Antenna Technology is a high-teach company in Guangdong Province. It is professionally engaged in designing, manufacturing and selling Car Antenna and mobile communication products, we always keep an eye on your demands and the developing trend of this industry, and have established a complete products system of car antenna. Our company has 10 years experience in manufacturing car antenna.The superior engineers provide precondition for product innovation, perfect production and testing equipment provide the quality guarantee for our products.
As the international enterprise, we are aiming at bringing customers the highest quality products to satisfy your expectation and needs, a large group of skilled technician work hard in order to increase the benefit for customers.
specification
| Origin | China |
| Brand | ATC |
| Model | ATC-M10 |
| GPS specification | |
| Frequency | 1575.42±1.023MHz |
| Center Frequency | 1575.42MHz |
| Bandwidth | 10 |
| VSWR | 1.5 |
| Polarization | RHCP |
| Patch Gain | 3dBi |
| Noise Figure | <1.6dB |
| LNA+Patch Gain | 23± 3dB |
| Output Impendace | 50 ohms |
| VSWR | <1.5:1 |
| Ratio | <4dB |
| Patch Dimension(mm) | 25*25 |
| Connector | SMA |
| Amplifier Gain | 28dB±3 |
| VSWR | 2.0 |
| Noise Figure | 4.0 |
| Work Voltage | 3.3V or 5V |
| Work Current | <15mA |
| AM/FM Specification | |
| Frequency | AM:535-1605KHZ |
| FM:87.5-108MHZ | |
| Gain | FM:8+/-3dB |
| AM:8+/-3dB | |
| Output Impendace | 75 ohms |
| VSWR | 2:1 |
| Noise Fig. | <4.5dB |
| DC Voltage | 12V |
| DC Current | 30-50mA |
| GPRS specification | |
| Frequency | 824-960MHz ,1710-1880MHz |
| VSWR | 1.5 |
| Impedance | 50 ohms |
| Gain | 2dBi |
packing
pratical application
