Basic Info.
Model NO.
ATC-M011
Base Antenna
High Gain Antenna
Nature of Operation
Receiving Antenna
Sturcture Form
Surface Antenna
Dimensionality
Two-Dimensional Antenna
Gain
8dB
Mast Length
200mm
Transport Package
Poly Bag/Color Box/Double Blister
Specification
RoHS
Trademark
ATC
Origin
Shenzhen
HS Code
8529102000
Production Capacity
30, 000 PCS/Month
Product Description
company information
Antenna Technology is a high-teach company in Guangdong Province. It is professionally engaged in designing, manufacturing and selling Car Antenna and mobile communication products, we always keep an eye on your demands and the developing trend of this industry, and have established a complete products system of car antenna.
Our company has 10 years experience in manufacturing car antenna. The superior engineers provide precondition for product innovation, perfect production and testing equipment provide the quality guarantee for our products.
As the international enterprise, we are aiming at bringing customers the highest quality products to satisfy your expectation and needs, a large group of skilled technician work hard in order to increase the benefit for customers.
specification
packing
pratical application
Antenna Technology is a high-teach company in Guangdong Province. It is professionally engaged in designing, manufacturing and selling Car Antenna and mobile communication products, we always keep an eye on your demands and the developing trend of this industry, and have established a complete products system of car antenna.
Our company has 10 years experience in manufacturing car antenna. The superior engineers provide precondition for product innovation, perfect production and testing equipment provide the quality guarantee for our products.
As the international enterprise, we are aiming at bringing customers the highest quality products to satisfy your expectation and needs, a large group of skilled technician work hard in order to increase the benefit for customers.
specification
| Origin | China |
| Brand | ATC |
| Model | ATC-M011 |
| Warranty | 3 years |
| DAB Frequency range | 170-237MHz(Band lll) |
| Output Gain | 12dB-18dB (Band lll) |
| Output impedance | 75 ohms |
| V.S.W.R | 3:1 |
| Noise Figure | less than 2dB |
| AM/FM Frequency range | am:520-1620KHz ,fm:87-108MHz |
| Gain | 7-12dB |
| Operating Voltage | DC10.5V-16V |
| Operating Current | 30mA-50mA |
| Work Temp | -30ºC--+80ºC |
| Storage Temp | -30ºC--+85ºC |
| Cable spec | 1.5DSQEHV ,for DAB ,1.5C2V for radio |
| Connector | SMA/SMB/FAKRA or Others for DAB , Motorola din plug for radio |
packing
pratical application
