Basic Info.
Model NO.
ul20851
Material Shape
Round Wire
Range of Application
Heat Resistance
Certification
ISO9001, RoHS, Reach
Brand
Bort
Conductor
Stranded, Tinned or Bare Copper Conductor Sample
Sample
Conventional Sample Free
Producing Experience
10 Years
No. of Cores
One Core or Multi-Cores
Colors
Could Be Customized Color
Delivery Time
in 7-10days
Packing
100m/Roll, 305m/Roll, Wrap Plastic Film Packaging
Company Type
Manufacturer
Service
OEM, ODM
Transport Package
100m/Roll, 305m/Roll, Wrap Plastic Film Packaging
Trademark
Bort
Origin
China
Production Capacity
300000km
Product Description
UL20851 Halogen Free Multimedia High Definition Interface electric cable
Product Description:
★ Rated temperature: 80ºC
Rated voltage: 30V
★ Reference Standard: High-Definition Multimedia Interface Specification
Version 1.0, IEC60754-2
★ Stranded/ solid bare or silver plated copper conductor of data pair, 32-
22 AWG
★ Colour-coded Foam-Skin-PE or PE insulation
★ Over 85% coverage tinned copper braid shield
★ FRPE jacket
★ Passes UL VW-1 FT1 vertical flame test
| Cores | Conductor | Insulation | Inner Shield | Separator Polyester Tape | Overall Shield | Jacket | Maximum Resistance at 20 ºC Ω/km | ||||||
| AWG | No./mm | Material | Nom. Thick. mm | Nom.Dia. mm | Drain Wire | Inside Shield AL. Mylar | Al. Mylar | Braid No./No./mm | Thick. mm | Nom. Dia. mm | |||
| 4P | 32 | 7/0.08 | Foam-Skin-PE | 0.22 | 0.68 | 32 | Y | Y | Y | 16/9/0.1 | 0.55 | 5.4 | 538 |
| 1P | 30 | 7/0.1 | PP | 0.12 | 0.54 | 354 | |||||||
| 4C | 30 | 7/0.1 | PP | 0.12 | 0.54 | 354 | |||||||
| 1C | 28 | 7/0.127 | PP | 0.11 | 0.60 | 223 | |||||||
| 4P | 30 | 7/0.1 | Foam-Skin-PE | 0.24 | 0.80 | 30 | Y | Y | Y | 16/8/0.12 | 0.55 | 5.7 | 354 |
| 1P | 30 | 7/0.1 | PP | 0.12 | 0.54 | 354 | |||||||
| 5C | 30 | 7/0.1 | PP | 0.12 | 0.54 | 354 | |||||||
| 4P | 28 | 7/0.127 | Foam-Skin-PE | 0.26 | 0.95 | 28 | Y | Y | Y | 16/11/0.12 | 0.55 | 7.3 | 223 |
| 1P | 28 | 7/0.127 | PP | 0.11 | 0.70 | 223 | |||||||
| 5C | 28 | 7/0.127 | PP | 0.11 | 0.70 | 223 | |||||||
| 4P | 26 | 7/0.16 | Foam-Skin-PE | 0.38 | 1.25 | 26 | Y | Y | Y | 24/9/0.1 | 0.65 | 8.2 | 130 |
| 1P | 26 | 7/0.16 | PP | 0.25 | 1.00 | 130 | |||||||
| 5C | 26 | 7/0.16 | PP | 0.25 | 1.00 | 130 | |||||||
| 4P | 24 | 19/0.127 | Foam-Skin-PE | 0.48 | 1.60 | 24 | Y | Y | Y | 24/11/0.10 | 0.65 | 9.3 | 77.6 |
| 1P | 26 | 7/0.16 | PP | 0.23 | 1.00 | 130 | |||||||
| 5C | 26 | 7/0.16 | PP | 0.23 | 1.00 | 130 | |||||||
| 4P | 22 | 19/0.147 | Foam-Skin-PE | 0.50 | 1.80 | 22 | Y | Y | Y | 24/12/0.10 | 0.65 | 10.2 | 57.6 |
| 1P | 26 | 7/0.16 | PP | 0.25 | 1.00 | 130 | |||||||
| 5C | 26 | 7/0.16 | PP | 0.25 | 1.00 | 130 | |||||||
