Basic Info.
Model NO.
DL-GPS-004
Base Antenna
Directional Antenna
Nature of Operation
Receiving Antenna
Sturcture Form
Surface Antenna
Dimensionality
Two-Dimensional Antenna
Frequency(MHz)
2400-2500
Polarization
Rhcp
Axial Ratio
3.0dB
Transport Package
Polybag, Paper Cartoon
Specification
Size: 46.60*15.60mm
Trademark
DeliNComm
Origin
China
HS Code
85291010
Production Capacity
50000000/Day
Product Description
2.4G Circular External Antenna Vibration Proof Antenna 2.4G Antenna
Mechanical Specifications
Conditions
Antenna Characteristics
Amplifier Characteristics
Environmental testing
Mechanical Specifications
| Size (mm) | Ø46.6*15.6mm | Mounting | Screw retainer |
| Weight(g) | 43g | Connector | SMA |
| Color | Black | Cable | RG174 - 3m |
Conditions
| Working Conditions | Temperature:-40ºC~+85ºC |
| Humidity: 95%~100% | |
| Storage Conditions | Temperature:-40ºC~+85ºC |
| Humidity: 95%~100% |
Antenna Characteristics
| No. | Item | Specifications | Post Environmental Tolerance |
| 1 | Range of Receiving Frequency(MHz) | 2400-2500 | ±2.5 |
| 2 | Center Frequency(MHz) (with 30mmSpuareGND plane) | 2400-2500 | ±3.0 |
| 3 | Band Width(MHz) (Return Loss≤-10dB) | ≥100 | |
| 4 | V.S.W.R(in Center Frequency) | ≤2.0 | |
| 5 | Gain (Zenith)(dBi typ) (with 70mmSquare GND plane) | ≤2.0 | ±0.5 |
| 6 | Axial Ratio (with 70mm Square GND plan) | 3.0dB | ±0.2 |
| 7 | Polarization | Right-Handed Circular | ---- |
| 8 | Impedance(Ω) | 50 | ---- |
| 9 | Frequency Temperature Coefficient (ppm/ºC) | 0±10 | ---- |
Amplifier Characteristics
| No. | Item | Specifications |
| 1 | Range Of Receiving Frequency | 2400-2500 |
| 2 | LAN Gain | 28±1 dB |
| 3 | In Center Frequency | ≤2.0 |
| 4 | Noise Figure | <2.0 |
| 5 | Supply Voltage | 3~5V |
| 6 | Current Consumption | 12±1mA@3VDC |
Environmental testing
| No. | Normal temperature performance | High temperature test performance deviation | Low temperature test performance deviation |
| 1 | LNA Gain 28±1 dB | ±2 | ±2 |
| 2 | V.S.W.R (in Center Frequency) ≤2.0 | ±0.3 | ±0.3 |
| 3 | Noise Figure <2.0 | ±0.3 | ±0.3 |
