Basic Info.
Model NO.
DL-GPS-0004
Base Antenna
High Gain Antenna
Nature of Operation
Receiving Antenna
Sturcture Form
Surface Antenna
Dimensionality
Two-Dimensional Antenna
Size
6*16*6.7mm
Logo
Delincomm
Weight
<10g
Transport Package
Polybag, Paper Carton
Specification
weight <10g
Origin
China
Production Capacity
35000/Day
Product Description
The GPS&GLONASS internal antenna consists of ceramic antenna, low noise amplifier and feed cable.
Characteristics:
low voltage 2.7~3.3V
Low noise coefficient: <2.0
Gain: 21±2dB
antenna structure
Technical characteristics
1.Antenna
2.Low noise amplifier
Characteristics:
low voltage 2.7~3.3V
Low noise coefficient: <2.0
Gain: 21±2dB
antenna structure
| Size | 15×15×6.7mm |
| Connector | SMA |
| Cable | 1.13(light gray) |
| Weight | <40g |
| Working Temperature | -40ºC~85ºC |
| Working Humidity | 10%~95% |
| Storage Temperature | -45ºC~85ºC |
| Storage Humidity | 10%~95% |
| Cable Length | 100mm |
1.Antenna
| Center frequency | 1575&1600MHz±5MHz |
| Tape width | 5MHZ |
| Gain(Maximum direction) | 0dB |
| Gain (10 degrees elevation) | -5dB |
| Polarization | Right-handed polarization |
| Impedance | 50Ω |
| Center frequency | 1575&1600MHz |
| Gain | 21dB±2dB |
| Noise Factor | ≤2.0dB |
| Standing-wave Ratio | ≤2.0 dB |
| Working Voltage | 2.7-3.3V |
| Working Current | 8±2mA |
| Impedance | 50Ω |
