Basic Info.
Model NO.
TW2
Warranty
1 Year
Function
Real Time GPS Car Tracking
Usage
All Kinds of Car
Network
4G GSM Quad Bands
APP
Ios and Android
Version
Asian Version/South American Version
Transport Package
Negotiated
Specification
L85mm*W61mm*H31mm and others
Trademark
supporting customization
Origin
Guangzhou, Guangdong, China
HS Code
8526911000
Production Capacity
50000pieces /Mouth
Packaging & Delivery
Package Size
20.00cm * 10.00cm * 6.00cm
Package Gross Weight
0.500kg
Product Description
enhanced version wireless 2g gps for vehicle fleet management with realtime monitoring
| Model | TW2 |
| GSM specifications | |
| GSM chip | MT2503 |
| GSM channel | 850/900/1800/1900MHz |
| GPRS class | |
| Communication mode | TCP/IP |
| Body memory | |
| Phase error | -5°~5° |
| Maximum output | GSM 850/900:33.0±2dbm GSM 1800/1900:30.0±2dbm |
| Maximum frequency error | ±0.1ppm |
| GPS specifications | |
| GPS chipset | MT2503 |
| Positioning mode | GPS+BD+LBS |
| frequency | L1,1575.42Mhz C/A code |
| Number of channels | 72 |
| Positioning accuracy | <10 meters |
| Tracking sensitivity | -162 dbm |
| Capture sensitivity | -160 dbm |
| Positioning time | Avg.hot start <2s Avg.warm Start <28s Avg.cold start <38s |
| Working parameters | |
| Operating voltage range | DC 5V/600mA(type-c) |
| Working current | 65.5mA/H |
| Quiescent current | 7.2mA |
| battery | 56*34*19mm³ 1200mAh 74*44*21mm³ 3000mAh 74*45*30mm³ 6000mAh 83*59*30mm³ 10000mAh |
| Continuous working time | |
| Continuous stationary battery life | |
| Storage capacity of blind spot track points | 300 |
| Operating temperature | -20°C to+60°C |
| Working humidity | -40ºC~+85ºC |
| Dimensions | TW2M 56*34*19mm³ 1200mAh TW2S 74*44*21mm³ 3000mAh TW2L 74*45*30mm³ 6000mAh TW2P 83*59*30mm³ 10000mAh |
| Weight | TW2M 56*34*19mm³ 49g TW2S 74*44*21mm³ 102g TW2L 74*45*30mm³ 151g TW2P 83*59*30mm³ 230g |
Guangzhou T-mark Technology Co., Ltd
Guangzhou T-mark Technology Co., Ltd is a company who can provide a series of GPS tracker (2G, 4G, wired gps tracker and wireless gps tracker) and professional tracking platform which support 186 models. And our factory was established in 2011, and mainly promoted GPS devices in domestic at the beginning, later, we have developed
overseas' agents in Domestic. Recent years, we have been developing overseas market by our own self.
Guangzhou T-mark Technology Co., Ltd is a company who can provide a series of GPS tracker (2G, 4G, wired gps tracker and wireless gps tracker) and professional tracking platform which support 186 models. And our factory was established in 2011, and mainly promoted GPS devices in domestic at the beginning, later, we have developed
overseas' agents in Domestic. Recent years, we have been developing overseas market by our own self.
Q1:Can you do hardware/software customization?
A: Yes, we offer not only OEM but ODM services, include online tracking platform.Our professional technician would also provide more after-sales service 7/24 hours
Q2. Does this GPS tracker need a sim card?
A:Yes.
Q3.How long will I get the goods after the payment?
A: This depends on quantity and logistics system. In normal condition, the goods will arrive at your address in 7-30 days. More details, please contact our sales for confirming.
Q4.Do you accept rebrand &logo custom?
A: Yes, rebrand on product case or product itself is available.
Q5.How are your quality control?
A: All products have been 100% strictly quality checked in the house before packing.
